DESCRIPTION

The PBC range of wall mounted loudspeakers is a real innovation in design and performance. These exceptional loudspeakers are both stylish and elegant, and offer a cost effective alternative to the conventional wooden cabinet loudspeaker.

The high reproduction of speech and background music distinguishes this series even further. The effortless and easy installation via a concealed attachment.

Areas of application represent premises in which value is attached design and excellent sound quality is laid, such bars, restaurants, hotels, reception rooms, prestigious rooms, medical office waiitng rooms, offices, etc.

• EN models are compliant to the EN54-24 standard for Voice Alarm systems.

• ENC models are compliant to the EN54-24 standard for Voice Alarm systems, it includes a capacitor for DC line monitoring.

FEATURES

Models:

• PBC6/T
• PBC10/TCOAX

EN54-24 Certified Models:

• PBC6T/EN
• PBC6T/ENC
• PBC10TCX/EN
• PBC10TCX/ENC

Certification:

• EN54-24:2008: Fire detection and fire alarm system - Certificat N° 0905-CPR-201109

SPECIFICATIONS

PBC6/T

• Rated power, Watts: 6
• Tappings 100 volt line, Watts: 6/3/1.5/0.75/0.25
• Transformer Impedance, Ohms, 100V: 1.67k/3.33k/6.66k/13.3k/39.9k
• Tappings 70.7 volt line, Watts: 3/1.5/0.75/0.25/0.125
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 160-18K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 96
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 104
• Dispersion at 1k/2k Hz, Degrees: 180/120

Environmental

• IP-Rating: 21
• Max/Min Amb Temp:  -10°C/+55°C
• Relative Humidity: ≤60%

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.15
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws

----------------------------------------------------------------------

PBC6T/EN

• Rated power, Watts: 6
• Tappings 100 volt line, Watts: 6/3/1.5/0.75/0.25
• Transformer Impedance, Ohms, 100V: 1.67k/3.33k/6.66k/13.3k/40k
• Tappings 70.7 volt line, Watts: 3/1.5/0.75/0.375/0.125
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 160-18K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 95
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 102
• Dispersion at 1k/2k Hz, Degrees: 119/100 (H) 77/99 (V)

Environmental

• IP-Rating: 21
• Max/Min Amb Temp: -10°C/+55°C
• Relative Humidity: ≤95%

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.15
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws
• Security: Ceramic Block, Thermal Fuse


----------------------------------------------------------------------

PBC6T/ENC

• Rated power, Watts: 6
• Tappings 100 volt line, Watts: 6/3/1.5/0.75/0.25
• Transformer Impedance, Ohms, 100V: 1.67k/3.33k/6.66k/13.3k/39.9k
• Tappings 70.7 volt line, Watts: 3/1.5/0.75/0.375/0.125
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 160-18K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 95
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 102
• Dispersion at 1k/2k Hz, Degrees: 119/100 (H) 77/99 (V)

Environmental

• IP-Rating: 21
• Max/Min Amb Temp: -10°C/+55°C
• Relative Humidity: ≤95%

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.15
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws
• Security: Ceramic Block, Thermal Fuse, Capacitor


----------------------------------------------------------------------

PBC10/TCOAX

Electrical

• Rated power, Watts: 10
• Tappings 100 volt line, Watts: 10/5/2.5/1.25
• Transformer Impedance, Ohms, 100V: 1k/2k/4k/8k
• Tappings 70.7 volt line, Watts: 5/2.5/1.25/0.625
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 80-20K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 89
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 99
• Dispersion at 1k/2k Hz, Degrees: 180/120

Environmental

• IP-Rating: n/a
• Max/Min Amb Temp: -10°C/+70°C
• Relative Humidity: n/a

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.40
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws

----------------------------------------------------------------------

PBC10TCX/EN

Electrical

• Rated power, Watts: 10
• Tappings 100 volt line, Watts: 10/5/2.5/1.25
• Transformer Impedance, Ohms, 100V: 1k/2k/4k/8k
• Tappings 70.7 volt line, Watts: 5/2.5/1.25/0.625
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 80-20K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 89
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 99
• Dispersion at 1k/2k Hz, Degrees: 132/96 (H) 169/96 (V)

Environmental

• IP-Rating: 21
• Max/Min Amb Temp: -10°C/+55°C
• Relative Humidity: ≤95%

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.15
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws
• Security: Ceramic Block, Thermal Fuse

----------------------------------------------------------------------

PBC10TCX/ENC

Electrical

• Rated power, Watts: 10
• Tappings 100 volt line, Watts: 10/5/2.5/1.25
• Transformer Impedance, Ohms, 100V: 1k/2k/4k/8k
• Tappings 70.7 volt line, Watts: 5/2.5/1.25/0.625
• Driver impedance, Ohms: 8
• Effective frequency range, Hz (BSEN60268-5): 80-20K
• S.P.L. @ 1 m, 1 Watt, dB, Octave, 100 Hz-10 kHz: 89
• S.P.L. @ 1 m, Full power, dB, Octave, 100 Hz-10 kHz: 99
• Dispersion at 1k/2k Hz, Degrees: 132/96 (H) 169/96 (V)

Environmental

• IP-Rating: 21
• Max/Min Amb Temp: -10°C/+55°C
• Relative Humidity: ≤95%

Mechanical

• Dimensions, front and depth, mm: 330 x 240 x 90
• Net Weight, Kgs: 1.15
• Colour (Unless Specified): White, RAL9016
• Material: ABS moulding with UV inhibitors Steel mesh
• Mounting: Screws
• Security: Ceramic Block, Thermal Fuse, Capacitor

APPLICATIONS

• Schools
• Stores
• Shopping malls
• Hotels
• Train stations
• Universities
• Industrial sites
